Benefits & Features: 5-Year Battery Powered; 6 Digit Display - Floating Decimal; Rate of Flow; Batch & Cumulative Totals; Factory Calibrated and Field Calibratable; Add-On Output Options; FM Approved Class I, Div. I; Choice of Gallons or Liters; Custom Programmable Display (including UOM)

Max Pressure Drop (at Max Flow in test conditions): 5 PSI

Accuracy (% of Reading) Factory Calibrated with Computer: ± 1.5%

Repeatability (based on test conditions): ± 0.2%

Maximum Viscosity: 100 cps**

Recommended Strainer Size: 35 Mesh (500 Microns)

Max. Particle Size: .018" / .457 mm

Operating Temp Without Local Computer or With Remote Computer: -40 to 250°F (-40 to 121°C) [Opt'l]

Housing Material: Nylon (see new model) <br><br>Search for new model<br>A1Q9GMN100NA (In Stock)

Bearings: Ceramic

Shaft: Tungsten Carbide

Rotor: Nylon

Signal Generator: Ferrite

Retaining Rings: 316SS

Display Function: Rate + 2 Totals (1 Resettable, 1 Cumulative)

Local Computer Calibrations: Factory & Field

LCD Digits: 6

Totalizing Display Starting Increment: 0.01

Typical K-Factor PPG (PPL): 730 (193)

Local Module & Output Signal: None

Remote Output: None

Sensor (Pickup): Magnetic

Battery Power: (2) 3V Lithium Battery (5 year)

Frequency Range: 36.5 - 608.3 Hz

Totalizing Resets to 0 After Reaching: 99999999

Applications (always check Chemical Compatibility Guide): Water, Non-Aggressive Chemicals

Not Suitable For Applications: DI Water

Application Notes: Unidirectional but Display can be rotated 180°, Can mount Horizontally or Vertically, Can use for Gravity Feeds, Line must be full (no air) for proper accuracy

Minimum Straight Pipe Dia.s: 20" Upstream / 5" Downstream

Desired Straight Pipe Dia.s: 40" Upstream / 10" Downstream

Connection to Connection Length (OAL): 4.0" (102 mm)

Shipping Weight (Approximate): 1.35 lbs (0.61 kg)
