Benefits & Features: Excellent for applications with fluctuating or multiple viscosities - No field calibrating required; Accuracy: ± 0.5% Of Reading; Up to 1,000 cps Viscosity; No straight pipe requirements; Bi-directional; PPS Rotors are immune to galling (adhesive wear); PPS Rotors produce less noise than metal rotors; 6 Digit Display - Floating Decimal; Rate of Flow; Batch & Cumulative Totals; Choice of Gallons or Liters; Custom Programmable Display (including UOM); Back-lighted Display when powered externally

Max Pressure Drop (at Max Flow in test conditions): Contact us

Accuracy (% of Reading) Factory Calibrated with Computer: ± 0.5% @ 3cp

Repeatability (based on test conditions): ± 0.03%

Maximum Viscosity: 1,000 cps

Recommended Strainer Size: 45 Mesh (350 Microns)

Max. Particle Size: .014" / .354 mm

Operating Temp Without Local Computer or With Remote Computer: 5 to 250°F (-15 to 120°C) [Opt'l]

Housing Material: Aluminum

Bearings: None

Shaft: Stainless Steel

Rotor: PPS

Seals: FKM (Viton™)

Display Function: Rate + 2 Totals (1 Resettable, 1 Cumulative)

LCD Digits: 6

Totalizing Display Starting Increment: 0.01

Typical K-Factor PPG (PPL): Reed: 5.68 (1.55), Hall Effect: 22.7 (6.00)

Local Module & Output Signal: None (RT40)

Remote Output: None

Battery Power: (1) 3.6V battery (~3 years)

External Power: Regulated 8-24VDC x 50mA minimum

Totalizing Resets to 0 After Reaching: 99999999

Sensor (Pickup): Reed Switch / Hall Effect<br>[Hall Effect Sensor requires dedicated power source]

Applications (always check Chemical Compatibility Guide): Metering clean fluids such as Oils, Grease, Fuels, Fuel Oils, Lubricating Liquids

Not Suitable For Applications: Water, dirty liquids

Minimum Straight Pipe Dia.s: None

Desired Straight Pipe Dia.s: None

Application Notes: The meter may be mounted horizontally or vertically but must be mounted, so the rotor shafts are in a horizontal plane (see manual), For viscous liquids, the maximum allowable flow may need to be reduced to ensure the pressure drop across the meter does NOT exceed 15 PSI, Viscosities <3cps, min. flow range is 10% of the maximum flow range, Line must be full (no air) for proper accuracy. External Power is required for the backlit display.

Connection to Connection Length (OAL): 15.0" (382mm)

Shipping Weight (Approximate): 61 lbs (27.7 kg)
