Benefits & Features: Excellent for applications with fluctuating or multiple viscosities - No field calibrating required; Accuracy: ± 0.5% Of Reading; Up to 1,000,000 cps Viscosity; No straight pipe requirements; Bi-directional; PPS Rotors are immune to galling (adhesive wear); PPS Rotors produce less noise than metal rotors

Max Pressure Drop (at Max Flow in test conditions): Contact us

Accuracy (% of Reading) Factory Calibrated with Computer: ± 0.5% @ 3cp

Repeatability (based on test conditions): ± 0.03%

Maximum Viscosity: 1,000,000 cps

Recommended Strainer Size: 45 Mesh (350 Microns)

Max. Particle Size: .014" / .354 mm

Operating Temp Without Local Computer or With Remote Computer: 5 to 250°F (-15 to 120°C)

Housing Material: Aluminum

Bearings: None

Shaft: Stainless Steel

Seals: FKM (Viton™)

Rotor: PPS (Hi Viscosity)

Typical K-Factor PPG (PPL): Reed: 4.15 (1.10), Hall Effect: 16.6 (4.40)

Local Module & Output Signal: Open Collector (NPN) Unscaled Pulse

Remote Output: None

Sensor (Pickup): Reed Switch / Hall Effect<br>[Hall Effect Sensor requires dedicated power source]

Applications (always check Chemical Compatibility Guide): Metering clean fluids such as Oils, Grease, Fuels, Fuel Oils, Lubricating Liquids

Not Suitable For Applications: Water, dirty liquids

Minimum Straight Pipe Dia.s: None

Desired Straight Pipe Dia.s: None

Application Notes: The meter may be mounted horizontally or vertically but must be mounted, so the rotor shafts are in a horizontal plane (see manual), For viscous liquids, the maximum allowable flow may need to be reduced to ensure the pressure drop across the meter does NOT exceed 15 PSI, Viscosities <3cps, min. flow range is 10% of the maximum flow range, Line must be full (no air) for proper accuracy

Connection to Connection Length (OAL): 11.6" (294mm)

Shipping Weight (Approximate): 52 lbs (23.6 kg)

Approvals Notes: CE Approval is applied when meter is part of a system
